CONTAINER M01
CONTAINER M01
The oversized 6x3 m container offers significantly wider interior space compared to the standard width of 2.4 m. Thanks to its 3-meter width, it provides a comfortable layout solution without the need to connect multiple modules.
It is suitable as an office, sales point, showroom, dispatch center or company facilities. The module is equipped with complete electrical installation and is ready for individual adjustments to the layout and placement of windows and doors.
Cladding: imitation wood, anthracite, or real wood cladding. The frame color can be customized according to company colors or logo
Optional extras:
- Doors and windows in various variants, reflective film
- Gastro serving windows
- Roller shutters, blinds, insect screens, security bars
- Air conditioning, electric heater
- Additional extras according to project requirements
Základní rozměr kontejneru M01:
300cm | 600cm | 18 m²
Floor plan
Variants
Gallery
Technical Specifications
| Container Type | M01 | |||
| Dimensions | Length | 600 cm | Width | 300 cm |
| Height | 268 cm | Clear Height | 236 cm | |
| Weight | 1500 kg | |||
| Technical Parameters | Snow Load | 50kg/m2 | Wind Speed | 60 km/h |
| Floor Load Capacity | 200kg/m2 | |||
| Thermal Conductivity (U-value) | Wall | 0,35(W/m2K) | Roof | 0,35 (W/m2K) |
| Construction | Bottom and Top Frame | Profiles 120x60x2,5mm | ||
| Corner Posts | TVL profile 120x120x2mm | |||
| Ceiling | Roof Covering | Sandwich panels: 80mm PUR panel (0,5mm sheet, PUR, 0,5mm sheet) | ||
| Walls | External Walls | 50 mm sandwich PUR panel with surface finish | ||
| Floor | Frame | Profiles 80x40x1,8mm with spacing 41cm | ||
| Insulation | 50 mm sandwich PUR panel | |||
| Floor Board | 12 mm OSB board | |||
| Floor Covering | 3 mm vinyl flooring | |||
| Doors | Exterior | Dimension | 90x200 cm | |
| Material | PVC | |||
| Windows and Glazing | Window | PVC, size 100x120 cm, opening and ventilation | ||
| Glazing | Double thermal glass 4 + 16 + 4mm | |||
| Color | Frames and Corners | RAL 7016, 3in1 coating | ||
| Walls | RAL 9002 | |||
| Electrical Installation | Connection |
Five-pin connection 400V/32A,PP/Y-5x2,5mm supply to switchboard, Main circuit breaker B16 3F |
||
| Sockets and Switches | CE-TSE certified - B16A breaker - RCD | |||
| Lighting | 2x ceiling LED light 24W/1700lm/6500k - B10A breaker - RCD | |||
| Lifting System | The container can be loaded and unloaded either using steel cables with hooks attached to corner eyes, or using forklift forks (recommended length 2.5m) | |||
| Warranty Conditions | BAUGRUP containers have a one-year warranty for all manufacturing and assembly defects. The warranty does not cover damage caused during transport. More details in the Terms and Conditions available at www.levnykontejner.cz. | |||
| Maintenance | To fully utilize its lifespan, it is necessary to follow the rules for its use and maintenance. More details in the Maintenance Manual available at www.levnykontejner.cz. | |||
